1 main technical parameters of production line

Applicable plank: ST37, Q235B

Suitable thickness: 3.0/4.0 m

About 133/207 of that material width: mm

Coil diameter: 508 mm Φ

The unit line speed: 0-20 m/min

2, production process and configuration overview

Production process: open book - into the material - leveling to roll bending, cutting and discharge

3, equipment composition:

1), a decoiler

2), into the feeding guide is a

3), a leveling machine

4), molding machine

5), shearing machine

A set of 6), discharging

7), a set of hydraulic system

8), a set of electric control system
